SHANTUI SD32 bulldozer SPECIFICATIONS

Operating weight (Ripper not included)

t

37.2

Engine

-

CumminsNTA855-C360S10

Rated power

kW/rpm

235/2000

Gradeability

°

30

Blade type

-

Straight tilt bladeSemi-U bladeAngle blade

Blade width

mm

Straight tilt blade 4130×1590Semi-U blade4030×1720Angle blade 5000×1140

Dozing capacity

m3

Straight tilt blade 10Semi-U blade 11.9Angle blade 6

Ma× drop below ground of blade

mm

560

Lift height of blade

mm

1560

Ripper type

-

Single ripperThree-shank ripper

Ripping depth of ripper

mm

Single ripper 1250Three-shank ripper 842

Lifting height of ripper

mm

Single ripper 955Three-shank ripper 883

Number of carriers (each side)

-

2

Number of track rollers (each side)

-

7

Number of track shoes (each side)

-

41

Width of track shoe

mm

760

Track gauge

mm

2140

Ground length and ground pressure

mm/MPa

3150-0.076

Pitch

mm

228.6

Forward speed

km/h

0–3.6

0–6.6

0–11.5

Reverse speed

km/h

0–4.4

0–7.8

0–13.5
