Brand：MAP
Spec：
Time：2018-12-05 11:09:02
Engine Details | |
Model | CHANGCHAI ZN385Q |
Engine type | In-line arrangement, water-cooled, 3singles cylinder diesel Engine |
Rated Power | 20KW, (26.82HP.) |
Rated Speed | 2200 r/min |
Min.ful consumption | 269 g/kw.h |
Bucket | |
Bucket Capacity | 0.4m3 |
Bucket type | Heavy-duty bolt on teeth |
Rated Load | 600 kg |
Operating Weight | 1800 kg |
Overall Dimensions | |
Overall Length | 4480 mm |
Overall Height | 2200 mm |
Overall Width | 1500 mm |
Max. discharge height | 2200 mm |
Wheel base | 1620 mm |
Tread | 1160 mm |
Operating Specifications | |
Steering System | Articulated Frame with hydraulic power steering |
Min Turning Radius | 3000 mm |
Transmission System | Manual clutch |
Brake System | |
Service Brake | Four Wheel Hydraulic spread-shoed brake |
Parking Brake | Hand operated |
Tyre | 750 |
